# Evolving Neural Networks through Augmenting Topologies – Part 3 of 4

This part of the NEAT tutorial will show how to use the RNeat package (not yet on CRAN) to solve the classic pole balance problem.

The simulation requires the implementation of 5 functions:

• processInitialStateFunc – This specifies the initial state of the system, for the pole balance problem the state is the cart location, cart velocity, cart acceleration, force being applied to the cart, pole angle, pole angular velocity and pole angular acceleration.
• processUpdateStateFunc – This specifies how to take the current state and update it using the outputs of the neural network. In this example this function simulates the equations of motion and takes the neural net output as the force that is being applied to the cart.
• processStateToNeuralInputFunc – Allows for modifying the state / normalisation of the state before it is passed as an input to the neural network
• fitnessUpdateFunc – Takes the old fitness, the old state and the new updated state and determines what the new system fitness is. For the pole balance problem this function wants to reward the pendulum being up right, and reward the cart being close to the middle of the track.
• terminationCheckFunc – Takes the state and checks to see if the termination should be terminated. Can chose to terminate if the pole falls over, the simulation has ran too long or the cart has driven off of the end of the track.
• plotStateFunc – Plots the state, for the pole balance this draws the cart and pendulum.

Onto the code:

?View Code RSPLUS
 install.packages("devtools") library("devtools") install_github("RNeat","ahunteruk") #Install from github as not yet on CRAN library("RNeat") drawPoleFunc <- function(fixedEnd.x,fixedEnd.y,poleLength, theta,fillColour=NA, borderColour="black"){ floatingEnd.x <- fixedEnd.x-poleLength * sin(theta) floatingEnd.y <- fixedEnd.y+poleLength * cos(theta)   polygon(c(fixedEnd.x,floatingEnd.x,floatingEnd.x,fixedEnd.x), c(fixedEnd.y,floatingEnd.y,floatingEnd.y,fixedEnd.y), col = fillColour, border=borderColour) }   drawPendulum <- function(fixedEnd.x,fixedEnd.y,poleLength, theta,radius,fillColour=NA, borderColour="black"){ floatingEnd.x <- fixedEnd.x-poleLength * sin(theta) floatingEnd.y <- fixedEnd.y+poleLength * cos(theta) createCircleFunc(floatingEnd.x,floatingEnd.y,radius,fillColour,borderColour) }   #Parameters to control the simulation simulation.timestep = 0.005 simulation.gravity = 9.8 #meters per second^2 simulation.numoftimesteps = 2000   pole.length = 1 #meters, total pole length pole.width = 0.2 pole.theta = pi/4 pole.thetaDot = 0 pole.thetaDotDot = 0 pole.colour = "purple"     pendulum.centerX = NA pendulum.centerY = NA pendulum.radius = 0.1 pendulum.mass = 0.1 pendulum.colour = "purple"   cart.width=0.5 cart.centerX = 0 cart.centerY = 0 cart.height=0.2 cart.colour="red" cart.centerXDot = 0 cart.centerXDotDot = 0 cart.mass = 0.4 cart.force = 0 cart.mu=2     track.limit= 10 #meters from center track.x = -track.limit track.height=0.01 track.y = 0.5*track.height track.colour = "blue"   leftBuffer.width=0.1 leftBuffer.height=0.2 leftBuffer.x=-track.limit-0.5*cart.width-leftBuffer.width leftBuffer.y=0.5*leftBuffer.height leftBuffer.colour = "blue"   rightBuffer.width=0.1 rightBuffer.height=0.2 rightBuffer.x=track.limit+0.5*cart.width rightBuffer.y=0.5*rightBuffer.height rightBuffer.colour = "blue"   #Define the size of the scene (used to visualise what is happening in the simulation) scene.width = 2*max(rightBuffer.x+rightBuffer.width,track.limit+pole.length+pendulum.radius) scene.bottomLeftX = -0.5*scene.width scene.height=max(pole.length+pendulum.radius,scene.width) scene.bottomLeftY = -0.5*scene.height   poleBalance.InitialState <- function(){ state <- list() state[1] <- cart.centerX state[2] <- cart.centerXDot state[3] <- cart.centerXDotDot state[4] <- cart.force state[5] <- pole.theta state[6] <- pole.thetaDot state[7] <- pole.thetaDotDot return(state) }   poleBalance.ConvertStateToNeuralNetInputs <- function(currentState){ return (currentState) }   poleBalance.UpdatePoleState <- function(currentState,neuralNetOutputs){ #print("Updating pole state") #print(neuralNetOutputs) cart.centerX <- currentState[[1]] cart.centerXDot <- currentState[[2]] cart.centerXDotDot <- currentState[[3]] cart.force <- currentState[[4]]+neuralNetOutputs[[1]] pole.theta <- currentState[[5]] pole.thetaDot <- currentState[[6]] pole.thetaDotDot <- currentState[[7]]   costheta = cos(pole.theta) sintheta = sin(pole.theta) totalmass = cart.mass+pendulum.mass masslength = pendulum.mass*pole.length   pole.thetaDotDot = (simulation.gravity*totalmass*sintheta+costheta*(cart.force-masslength*pole.thetaDot^2*sintheta-cart.mu*cart.centerXDot))/(pole.length*(totalmass-pendulum.mass*costheta^2))   cart.centerXDotDot = (cart.force+masslength*(pole.thetaDotDot*costheta-pole.thetaDot^2*sintheta)-cart.mu*cart.centerXDot)/totalmass   cart.centerX = cart.centerX+simulation.timestep*cart.centerXDot cart.centerXDot = cart.centerXDot+simulation.timestep*cart.centerXDotDot pole.theta = (pole.theta +simulation.timestep*pole.thetaDot ) pole.thetaDot = pole.thetaDot+simulation.timestep*pole.thetaDotDot   currentState[1] <- cart.centerX currentState[2] <- cart.centerXDot currentState[3] <- cart.centerXDotDot currentState[4] <- cart.force currentState[5] <- pole.theta currentState[6] <- pole.thetaDot currentState[7] <- pole.thetaDotDot return (currentState) }       poleBalance.UpdateFitness <- function(oldState,updatedState,oldFitness){ #return (oldFitness+1) #fitness is just how long we've ran for #return (oldFitness+((track.limit-abs(updatedState[[1]]))/track.limit)^2) #More reward for staying near middle of track   height <- cos(updatedState[[5]]) #is -ve if below track heightFitness <- max(height,0) centerFitness <- (track.limit-abs(updatedState[[1]]))/track.limit return (oldFitness+(heightFitness + heightFitness*centerFitness)) }   poleBalance.CheckForTermination <- function(frameNum,oldState,updatedState,oldFitness,newFitness){ cart.centerX <- updatedState[[1]] cart.centerXDot <- updatedState[[2]] cart.centerXDotDot <- updatedState[[3]] cart.force <- updatedState[[4]] pole.theta <- updatedState[[5]] pole.thetaDot <- updatedState[[6]] pole.thetaDotDot <- updatedState[[7]]   oldpole.theta <- oldState[[5]] if(frameNum > 20000){ print("Max Frame Num Exceeded , stopping simulation") return (T) }   height <- cos(pole.theta) oldHeight <- cos(oldpole.theta) if(height==-1 & cart.force==0){ return(T) }   if(oldHeight >= 0 & height < 0){ #print("Pole fell over") return (T) } if(cart.centerX < track.x | cart.centerX > (track.x+2*track.limit)){ #print("Exceeded track length") return (T) } else { return (F) } }   poleBalance.PlotState <-function(updatedState){ cart.centerX <- updatedState[[1]] cart.centerXDot <- updatedState[[2]] cart.centerXDotDot <- updatedState[[3]] cart.force <- updatedState[[4]] pole.theta <- updatedState[[5]] pole.thetaDot <- updatedState[[6]] pole.thetaDotDot <- updatedState[[7]]   createSceneFunc(scene.bottomLeftX,scene.bottomLeftY,scene.width,scene.height, main="Simulation of Inverted Pendulum - www.gekkoquant.com",xlab="", ylab="",xlim=c(-0.5*scene.width,0.5*scene.width),ylim=c(-0.5*scene.height,0.5*scene.height))   createBoxFunc(track.x,track.y,track.limit*2,track.height,track.colour) createBoxFunc(leftBuffer.x,leftBuffer.y,leftBuffer.width,leftBuffer.height,leftBuffer.colour) createBoxFunc(rightBuffer.x,rightBuffer.y,rightBuffer.width,rightBuffer.height,rightBuffer.colour) createBoxFunc(cart.centerX-0.5*cart.width,cart.centerY+0.5*cart.height,cart.width,cart.height,cart.colour) drawPoleFunc(cart.centerX,cart.centerY,2*pole.length,pole.theta,pole.colour) drawPendulum(cart.centerX,cart.centerY,2*pole.length,pole.theta,pendulum.radius,pendulum.colour)   }   config <- newConfigNEAT(7,1,500,50) poleSimulation <- newNEATSimulation(config, poleBalance.InitialState, poleBalance.UpdatePoleState, poleBalance.ConvertStateToNeuralNetInputs, poleBalance.UpdateFitness, poleBalance.CheckForTermination, poleBalance.PlotState)   for(i in seq(1,1000)){ poleSimulation <- NEATSimulation.RunSingleGeneration(poleSimulation,T,"videos","poleBalance",1/simulation.timestep) }

# Evolving Neural Networks through Augmenting Topologies – Part 2 of 4

This part of the tutorial on using NEAT algorithm explains how genomes are crossed over in a meaningful way maintaining their topological information and how speciation (group genomes into species) can be used to protect weak genomes with new topological information from prematurely being eradicated from the gene pool before their weight space can be optimised.

The first part of this tutorial can be found here.

Tracking Gene History through Innovation Numbers

Part 1 showed two mutations, link mutate and node mutate which both added new genes to the genome. Each time a new gene is created (through a topological innovation) a global innovation number is incremented and assigned to that gene.

The global innovation number is tracking the historical origin of each gene. If two genes have the same innovation number then they must represent the same topology (although the weights may be different). This is exploited during the gene crossover.

Genome Crossover (Mating)

Genomes crossover takes two parent genomes (lets call them A and B) and creates a new genome (lets call it the child) taking the strongest genes from A and B copying any topological structures along the way.

During the crossover genes from both genomes are lined up using their innovation number. For each innovation number the gene from the most fit parent is selected and inserted into the child genome. If both parent genomes are the same fitness then the gene is randomly selected from either parent with equal probability. If the innovation number is only present in one parent then this is known as a disjoint or excess gene and represents a topological innovation, it too is inserted into the child.

The image below shows the crossover process for two genomes of the same fitness.

Speciation

Speciation takes all the genomes in a given genome pool and attempts to split them into distinct groups known as species. The genomes in each species will have similar characteristics.

A way of measuring the similarity between two genomes is required, if two genomes are “similar” they are from the same species. A natural measure to use would be a weighted sum of the number of disjoint & excess genes (representing topological differences) and the difference in weights between matching genes. If the weighted sum is below some threshold then the genomes are of the same species.

The advantage of splitting the genomes into species is that during the genetic evolution step where genomes with low fitness are culled (removed entirely from the genome pool) rather than having each genome fight for it’s place against every other genome in the entire genome pool we can make it fight for it’s place against genomes of the same species. This way species that form from a new topological innovation that might not have a high fitness yet due to not having it’s weights optimised will survive the culling.

Summary of whole process

• Create a genome pool with n random genomes
• Take each genome and apply to problem / simulation and calculate the genome fitness
• Assign each genome to a species
• In each species cull the genomes removing some of the weaker genomes
• Breed each species (randomly select genomes in the species to either crossover or mutate)
• Repeat all of the above

# Evolving Neural Networks through Augmenting Topologies – Part 1 of 4

This four part series will explore the NeuroEvolution of Augmenting Topologies (NEAT) algorithm. Parts one and two will briefly out-line the algorithm and discuss the benefits, part three will apply it to the pole balancing problem and finally part 4 will apply it to market data.

This algorithm recently went viral in a video called MarI/O where a network was developed that was capable of completing the first level of super mario see the video below.

Typically when one chooses to use a neural network they have to decide how many hidden layers there are, the number of neurons in each layer and what connections exist between the neurons. Depending on the nature of the problem it can be very difficult to know what is a sensible topology. Once the topology is chosen it will most likely be trained using back-propagation or a genetic evolution approach and tested. The genetic evolution approach is essentially searching through the space of connection weights and selecting high performing networks and breeding them (this is known as fixed-topology evolution).

The above approach finds optimal connection weights, it’s then down to an “expert” to manually tweak the topology of the network in an attempt to iteratively find better performing networks.

This led to the development of variable-topology training, where both the connection space and structure space are explored. With this came a host of problems such as networks becoming incredibly bushy and complex slowing down the machine learning process. With the genetic approaches it was difficult to track genetic mutations and crossover structure in a meaningful way.

The NEAT algorithm aims to develop a genetic algorithm that searching through neural network weight and structure space that has the following properties:

1. Have genetic representation that allows structure to be crossed over in a meaningful way
2. Protect topological innovations that need a few evolutions to be optimised so that it doesn’t disappear from the gene pool prematurely
3. Minimise topologies throughout training without specially contrived network complexity penalisation functions

A through treatment of the algorithm can be found in the paper Evolving Neural Networks through

The information about the network is represented by a genome, the genome contains node genes and connection genes. The node genes define nodes in the network, the nodes can be inputs (such as a technical indicator), outputs (such as a buy / sell recommendation), or hidden (used by the network for a calculation). The connection genes join nodes in the network together and have a weight attached to them.

Connection genes have an input node, an output node, a weight, an enabled/disabled flag and an innovation number. The innovation number is used to track the history of a genes evolution and will be explained in more detail in part two.

This post will look at some of the mutations that can happen to the network, it is worth noting that each genome has embedded inside it a mutation rate for each type of mutation that can occur. These mutation rates are also randomly increased or decreased as the evolution progresses.

Point Mutate

Randomly updates the weight of a randomly selected connection gene

New Weight = Old Weight +/- Random number between 0 and genome\$MutationRate[[“Step”]]

or

New Weight = Random number between -2 and 2

Randomly adds a new connection to the network with a random weight between -2 and 2

Node Mutate

This mutation adds a new node to the network by disabling a connection, replacing it with a connection of weight 1, a node and a connection with the same weight as the disabled connection. In essence it’s been replaced with an identically functioning equivalent.

Enable Disable Mutate

Randomly enables and disables connections

# Inverted Pendulum Simulation in R

This post will derive the equations of motion and simulate the classic inverted pendulum control problem. Subsequent posts will apply machine learning to figure out how to control the pendulum and keep it up in the air.

A video of the simulation can be found at:

The derivation of the maths follows the approach outlined in the following video, however I have decided to model the friction between the cart and track.

## Free body diagram of pendulum

Resolve the forces on the free body diagrams and set equal to their acceleration

$\text{Cart (0),}\hat{i}:F-TSin\theta-\mu\dot{x}=m_{c}\ddot{x}$
$\text{Pendulum (1),}\hat{i}:TSin\theta=m_{p}a_{px}$
$\text{Pendulum (2),}\hat{j}:-TCos\theta-m_{p}g=m_{p}a_{pg}$

## Definition of e co-ordinate system

The acceleration of the pendulum is the acceleration of the cart plus the acceleration of the pendulum relative to the cart

$\underline{a_{p}}=\underline{a_{c}}+\underline{a_{p/c}}=\ddot{x}\hat{i}+L\ddot{\theta}\hat{e}_{\theta}+L\dot{\theta^{2}}\hat{e}_{r}$

Convert the co-ordinate system back into the $\hat{i}$ and $\hat{j}$ components

$\underline{a_{p}}=\ddot{x}\hat{i}+L\ddot{\theta}[-Cos\theta\hat{i}-Sin\theta\hat{j}]-L\dot{\theta^{2}}[-Sin\theta\hat{i}+Cos\theta\hat{j}]$

Substitute the accelerations into equation (1) and (2)

$(1):TSin\theta=m_{p}\ddot{x}-m_{p}L\ddot{\theta}Cos\theta+m_{p}L\dot{\theta^{2}}Sin\theta\text{ Eq(3)}$
$(2):-TCos\theta-m_{p}g=-m_{p}L\ddot{\theta}Sin\theta-m_{p}L\dot{\theta^{2}}Cos\theta\text{ Eq(4)}$

It is undesirable to have an unknown tension T so eliminate using a trick.

$(3)Cos\theta+(4)Sin\theta:$
$TSin\theta Cos\theta-TCos\theta Sin\theta-m_{p}gSin\theta=m_{p}\ddot{x}Cos\theta-m_{p}L\ddot{\theta}Cos^{2}\theta+m_{p}L\dot{\theta^{2}}Sin\theta Cos\theta+-m_{p}L\ddot{\theta}Sin^{2}\theta-m_{p}L\dot{\theta^{2}}Cos\theta Sin\theta$
$-m_{p}gSin\theta=m_{p}\ddot{x}Cos\theta-m_{p}L\ddot{\theta}Cos^{2}\theta+Sin^{2}\theta)+m_{p}L\dot{\theta^{2}}(Sin\theta Cos\theta-Cos\theta Sin\theta)$
$-m_{p}gSin\theta=m_{p}\ddot{x}Cos\theta-m_{p}L\ddot{\theta}\text{ Eq(5)}$

Substitute equation (1) into equation (0)

$(0)\&(1):F-m_{p}\ddot{x}+m_{p}L\ddot{\theta}Cos\theta-m_{p}L\dot{\theta^{2}Sin\theta}-\mu\dot{x}=m_{c}\ddot{x}$
$(0)\&(1):F+m_{p}L\ddot{\theta}Cos\theta-m_{p}L\dot{\theta^{2}Sin\theta}-\mu\dot{x}=(m_{c}-m_{p})\ddot{x}\text{ Eq(6)}$

Rearranging equation (6) and (5) gives the system equations in known measurable variables

$\ddot{x}=\frac{F+m_{p}L[\ddot{\theta Cos\theta}-\dot{\theta^{2}}Sin\theta]-\mu\dot{x}}{m_{c}+m_{p}}$
$\ddot{\theta}=\frac{\ddot{x}Cos\theta+gSin\theta}{L}$

Both the acceleration terms $\ddot{x}$ and $\ddot{\theta}$ depend on each other which is undesirable, substitute the equation for $\ddot{x}$ into the equation for $\ddot{\theta}$ to remove the dependency

$L\ddot{\theta}=\ddot{x}Cos\theta+gSin\theta$
$L\ddot{\theta}=\frac{FCos\theta+m_{p}LCos\theta[\ddot{\theta}Cos\theta-\dot{\theta^{2}}Sin\theta]-\mu Cos\theta\dot{x}}{m_{c}+m_{p}}+gSin\theta$
$L(m_{c}+m_{p})\ddot{\theta}=FCos\theta+m_{p}LCos\theta[\ddot{\theta}Cos\theta-\dot{\theta^{2}}Sin\theta]-\mu Cos\theta\dot{x}+g(m_{c}+m_{p})Sin\theta$
$L(m_{c}+m_{p}-m_{p}Cos^{2}\theta)\ddot{\theta}=FCos\theta-m_{p}L\dot{\theta^{2}}Cos\theta Sin\theta-\mu Cos\theta\dot{x}+g(m_{c}+m_{p})Sin\theta$
$\ddot{\theta}=\frac{FCos\theta-m_{p}L\dot{\theta^{2}}Cos\theta Sin\theta-\mu Cos\theta\dot{x}+g(m_{c}+m_{p})Sin\theta}{L(m_{c}+m_{p}-m_{p}Cos^{2}\theta)}$
$\ddot{\theta}=\frac{g(m_{c}+m_{p})Sin\theta+Cos\theta[F-m_{p}L\dot{\theta^{2}}Sin\theta-\mu\dot{x}]}{L(m_{c}+m_{p}-m_{p}Cos^{2}\theta)}$

The system can then be simulated using Euler update equations:

$x_{t+\Delta t}=x_{t}+\dot{x}\Delta t$
$\dot{x}_{t+\Delta t}=\dot{x}_{t}+\ddot{x}\Delta t$
$\theta_{t+\Delta t}=\theta_{t}+\dot{\theta}\Delta t$
$\dot{\theta}_{t+\Delta t}=\dot{\theta}_{t}+\ddot{\theta}\Delta t$

On to the code:

?View Code RSPLUS
 library("animation") #Library to save GIFs   #Function to create a blank canvas / scene for drawing objects onto later createSceneFunc <- function(bottomLeftX, bottomLeftY, width,height,main="",xlab="",ylab="",ann=T,xaxt=NULL,yaxt=NULL,xlim=NULL,ylim=NULL){ plot(c(bottomLeftX, width), c(bottomLeftY,height), type = "n",ann=ann, xaxt=xaxt, yaxt=yaxt,xlim=xlim,ylim=ylim,main=main,xlab=xlab,ylab=ylab ) }   #Function to draw a box on the scene createBoxFunc <- function(topLeftX, topLeftY, width, height, fillColour=NA, borderColour="black"){ polygon(c(topLeftX,topLeftX+width,topLeftX+width,topLeftX), c(topLeftY,topLeftY,topLeftY-height,topLeftY-height), col = fillColour, border=borderColour) }   #Function to draw a circle on the scene createCircleFunc <- function(centerX,centerY,radius,fillColour=NA, borderColour="black"){ symbols(centerX,centerY,circles=radius,inches=F,add=T,fg=borderColour,bg=fillColour) }   drawPoleFunc <- function(fixedEnd.x,fixedEnd.y,poleLength, theta,fillColour=NA, borderColour="black"){ floatingEnd.x <- fixedEnd.x+poleLength * sin(theta) floatingEnd.y <- fixedEnd.y+poleLength * cos(theta)   polygon(c(fixedEnd.x,floatingEnd.x,floatingEnd.x,fixedEnd.x), c(fixedEnd.y,floatingEnd.y,floatingEnd.y,fixedEnd.y), col = fillColour, border=borderColour) }   drawPendulum <- function(fixedEnd.x,fixedEnd.y,poleLength, theta,radius,fillColour=NA, borderColour="black"){ floatingEnd.x <- fixedEnd.x+poleLength * sin(theta) floatingEnd.y <- fixedEnd.y+poleLength * cos(theta) createCircleFunc(floatingEnd.x,floatingEnd.y,radius,fillColour,borderColour) }   #Parameters to control the simulation simulation.timestep = 0.02 simulation.gravity = 9.8 #meters per second^2 simulation.numoftimesteps = 2000   pole.length = 1 #meters, total pole length pole.width = 0.2 pole.theta = 1*pi/4 pole.thetaDot = 0 pole.thetaDotDot = 0 pole.colour = "purple"     pendulum.centerX = NA pendulum.centerY = NA pendulum.radius = 0.1 pendulum.mass = 1 pendulum.colour = "purple"   cart.width=0.5 cart.centerX = 0 cart.centerY = 0 cart.height=0.2 cart.colour="red" cart.centerXDot = 0 cart.centerXDotDot = 0 cart.mass = 1 cart.force = 0 cart.mu=2     track.limit= 2.4 #meters from center track.x = -track.limit track.height=0.01 track.y = 0.5*track.height track.colour = "blue"   leftBuffer.width=0.1 leftBuffer.height=0.2 leftBuffer.x=-track.limit-0.5*cart.width-leftBuffer.width leftBuffer.y=0.5*leftBuffer.height leftBuffer.colour = "blue"   rightBuffer.width=0.1 rightBuffer.height=0.2 rightBuffer.x=track.limit+0.5*cart.width rightBuffer.y=0.5*rightBuffer.height rightBuffer.colour = "blue"   #Define the size of the scene (used to visualise what is happening in the simulation) scene.width = 2*max(rightBuffer.x+rightBuffer.width,track.limit+pole.length+pendulum.radius) scene.bottomLeftX = -0.5*scene.width scene.height=max(pole.length+pendulum.radius,scene.width) scene.bottomLeftY = -0.5*scene.height       #Some variables to store various time series values of the simulation logger.trackposition = rep(NA,simulation.numoftimesteps) logger.force = rep(NA,simulation.numoftimesteps) logger.cartvelocity = rep(NA,simulation.numoftimesteps) logger.poletheta = rep(NA,simulation.numoftimesteps)   #Some settings to control the charts used to plot the logged variables plotcontrol.trackposition.ylim = c(0,10) plotcontrol.force.ylim = c(-6,6) plotcontrol.yacceleration.ylim = c(-simulation.gravity,400) plotcontrol.poletheta.ylim = c(0,360)       runSimulationFunc <- function(){ simulationAborted = FALSE #Main simulation loop for(i in seq(1,simulation.numoftimesteps)){   costheta = cos(pole.theta) sintheta = sin(pole.theta) totalmass = cart.mass+pendulum.mass masslength = pendulum.mass*pole.length   pole.thetaDotDot = (simulation.gravity*totalmass*sintheta+costheta*(cart.force-masslength*pole.thetaDot^2*sintheta-cart.mu*cart.centerXDot))/(pole.length*(totalmass-pendulum.mass*costheta^2))   cart.centerXDotDot = (cart.force+masslength*(pole.thetaDotDot*costheta-pole.thetaDot^2*sintheta)-cart.mu*cart.centerXDot)/totalmass   cart.centerX = cart.centerX+simulation.timestep*cart.centerXDot cart.centerXDot = cart.centerXDot+simulation.timestep*cart.centerXDotDot pole.theta = (pole.theta +simulation.timestep*pole.thetaDot ) pole.thetaDot = pole.thetaDot+simulation.timestep*pole.thetaDotDot   if(cart.centerX <= track.x | cart.centerX >= (track.x+2*track.limit)){ cart.colour="black" simulationAborted = TRUE }     #Log the results of the simulation logger.trackposition[i] <- cart.centerX logger.force[i] <- cart.force logger.cartvelocity[i] <- cart.centerXDot logger.poletheta[i] <- pole.theta   #Plot the simulation #The layout command arranges the charts layout(matrix(c(1,2,1,3,1,4,1,5,6,6), 5, 2, byrow = TRUE),heights=c(2,2,2,2,1)) par(mar=c(3,4,2,2) + 0.1)   #Create the scene and draw the various objects createSceneFunc(scene.bottomLeftX,scene.bottomLeftY,scene.width,scene.height, main="Simulation of Inverted Pendulum - www.gekkoquant.com",xlab="", ylab="",xlim=c(-0.5*scene.width,0.5*scene.width),ylim=c(-0.5*scene.height,0.5*scene.height))   createBoxFunc(track.x,track.y,track.limit*2,track.height,track.colour) createBoxFunc(leftBuffer.x,leftBuffer.y,leftBuffer.width,leftBuffer.height,leftBuffer.colour) createBoxFunc(rightBuffer.x,rightBuffer.y,rightBuffer.width,rightBuffer.height,rightBuffer.colour) createBoxFunc(cart.centerX-0.5*cart.width,cart.centerY+0.5*cart.height,cart.width,cart.height,cart.colour) drawPoleFunc(cart.centerX,cart.centerY,2*pole.length,pole.theta,pole.colour) drawPendulum(cart.centerX,cart.centerY,2*pole.length,pole.theta,pendulum.radius,pendulum.colour) #Plot the logged variables plot(logger.trackposition, type="l",ylab="Cart Position")#, ylim=plotcontrol.trackposition.ylim, ylab="Y POSITION") plot(logger.force, type="l", ylab="Cart FORCE") #, ylim=plotcontrol.force.ylim, ylab="Y VELOCITY") plot(logger.cartvelocity, type="l", ylab="Cart VELOCITY")#,ylim=plotcontrol.yacceleration.ylim, ylab="Y ACCELERATION") plot(logger.poletheta*360/(2*pi), type="l", ylab="Pole THETA")#,ylim=plotcontrol.yacceleration.ylim, ylab="Y ACCELERATION")   #Plot a progress bar par(mar=c(2,1,1,1)) plot(-5, xlim = c(1,simulation.numoftimesteps), ylim = c(0, .3), yaxt = "n", xlab = "", ylab = "", main = "Iteration") abline(v=i, lwd=5, col = rgb(0, 0, 255, 255, maxColorValue=255))   if(simulationAborted){ break } } }   #runSimulationFunc() oopt = ani.options(ani.width = 1200, ani.height = 800, other.opts = "-pix_fmt yuv420p -b 600k") saveVideo(runSimulationFunc(),interval = simulation.timestep,ani.options=oopt,video.name="inverted-pendulum.mp4") ani.options(oopt)

# Animation in R – Bouncing Ball Simulation

This post fill focus on how to create an animation to visualise the simulation of a physical system, in this case a bouncing ball. Whilst this post is unrelated to trading it will form the basis of future articles. In my next post I will show how to simulate the classic pole balancing / inverted pendulum problem. Machine learning will then be applied to develop a control system for the dynamic systems.

A video of the simulation is below:

Creating Animations

The R package “animation” has been used to create videos of the simulated process. This package requires that FFMpeg is installed on your machine and added to your environmental path. To learn how to add items to your path follow this tutorial at Geeks With Blogs.

The code below demonstrated how to generate a video:

?View Code RSPLUS
 oopt = ani.options(ani.width = 1200, ani.height = 800, other.opts = "-pix_fmt yuv420p -b 600k") saveVideo(runSimulationFunc(),interval = simulation.timestep,ani.options=oopt,video.name="bounce.mp4") ani.options(oopt)
• ani.width is the width of the video
• ani.height is the height of the video
• other.opts are command line arguments that are passed to ffmpeg and can be used to control the bitrate and other quality settings
• interval specifies in seconds how long to wait between frames
• runSimulationFunc() is a function that should run your simulation, and charts plotted during the simulation will be added to the video

Drawing Graphics

I have written some functions to make drawing basic graphics easy.

• createSceneFunc(bottomLeftX, bottomLeftY, width,height) creates a brand new scene to draw objects on, bottomLeftX and bottomLeftY are Cartesian co-ordinates to specify the bottom left corner of the canvas. The width and height variables are used to specify the canvas dimensions.
• createBoxFunc(topLeftX, topLeftY, width, height, fillColour) draws a box to the current canvas, topLeftX and topLeftY specify the Cartesian co-ordinate of the top left of the box, width and height specify the dimensions and fillColour specifies the colour that fills in the box.
• createCircleFunc(centerX,centerY,radius,fillColour) draws a circle to the current canvas, centerX and centerY specify the Cartesian co-ordinate of the center on the circle, the radius specifies the radius of the circle and fillColour specifies the colour that fills in the circle.

Simulation Dynamics

The following single period update equations are used:
$Position_{t+\Delta t}=Position_{t}+Velocity_{t}*\Delta t$
$Velocity_{t+\Delta t}=Velocity_{t}+Acceleration_{t}*\Delta t$

When a collision is made between the ball and the platform the following update is used:
$Velocity_{t+\Delta t}=-\kappa*Velocity_{t}$
$\kappa=\text{Coefficient of restitution}$

Onto the code:

?View Code RSPLUS
 library("animation") #Library to save GIFs   #Function to create a blank canvas / scene for drawing objects onto later createSceneFunc <- function(bottomLeftX, bottomLeftY, width,height,main="",xlab="",ylab="",ann=T,xaxt=NULL,yaxt=NULL){ plot(c(bottomLeftX, width), c(bottomLeftY,height), type = "n",ann=ann, xaxt=xaxt, yaxt=yaxt,main=main,xlab=xlab,ylab=ylab ) }   #Function to draw a box on the scene createBoxFunc <- function(topLeftX, topLeftY, width, height, fillColour=NA, borderColour="black"){ polygon(c(topLeftX,topLeftX+width,topLeftX+width,topLeftX), c(topLeftY,topLeftY,topLeftY-height,topLeftY-height), col = fillColour, border=borderColour) }   #Function to draw a circle on the scene createCircleFunc <- function(centerX,centerY,radius,fillColour=NA, borderColour="black"){ symbols(centerX,centerY,circles=radius,inches=F,add=T,fg=borderColour,bg=fillColour) }   #Parameters to control the simulation simulation.timestep = 0.02 simulation.gravity = 1.8 simulation.numoftimesteps = 2000   #Define the size of the scene (used to visualise what is happening in the simulation) scene.bottomLeftX = 0 scene.bottomLeftY = -1 scene.width = 10 scene.height=10   #This is the object the bouncing ball is going to hit platform.x = scene.bottomLeftX+1 platform.y = 0 platform.width= scene.width - 2 platform.height=0.5 platform.colour = "red"   #This is just a box resting on the left end of the platform to practise drawing things leftbluebox.x = platform.x leftbluebox.y = platform.y+0.5 leftbluebox.width=0.5 leftbluebox.height=0.5 leftbluebox.colour = "blue"   #This is just a box resting on the right end of the platform to practise drawing things rightbluebox.x = platform.x+platform.width-0.5 rightbluebox.y = platform.y+0.5 rightbluebox.width=0.5 rightbluebox.height=0.5 rightbluebox.colour = "blue"   #This is the ball that is going to be bouncing ball.y=10 ball.x=5 ball.radius = 0.25 ball.yvelocity = 0 ball.yacceleration = 0 ball.coefficientofrestitution = 0.85 #This is a physics term to describe how much velocity as pct is kept after a bounce ball.colour="purple"   #Some variables to store various time series values of the simulation logger.yposition = rep(NA,simulation.numoftimesteps) logger.yvelocity = rep(NA,simulation.numoftimesteps) logger.yacceleration = rep(NA,simulation.numoftimesteps)   #Some settings to control the charts used to plot the logged variables plotcontrol.yposition.ylim = c(0,10) plotcontrol.yvelocity.ylim = c(-6,6) plotcontrol.yacceleration.ylim = c(-simulation.gravity,400)   runSimulationFunc <- function(){ #Main simulation loop for(i in seq(1,simulation.numoftimesteps)){   #Equations of motion ball.yacceleration = -simulation.gravity ball.y = ball.y + ball.yvelocity*simulation.timestep ball.yvelocity = ball.yvelocity+ball.yacceleration*simulation.timestep   #Logic to check is there has been a collision between the ball and the platform if(ball.y-ball.radius <= platform.y){ #There has been a collision newyvelocity = -ball.yvelocity*ball.coefficientofrestitution ball.yacceleration = (newyvelocity - ball.yvelocity)/simulation.timestep ball.yvelocity = newyvelocity ball.y = ball.radius+platform.y }   #Log the results of the simulation logger.yposition[i] <- ball.y logger.yvelocity[i] <- ball.yvelocity logger.yacceleration[i] <- ball.yacceleration   #Plot the simulation #The layout command arranges the charts layout(matrix(c(1,2,1,3,1,4,5,5), 4, 2, byrow = TRUE),heights=c(3,3,3,1)) par(mar=c(3,4,2,2) + 0.1)   #Create the scene and draw the various objects #Create the scene createSceneFunc(scene.bottomLeftX,scene.bottomLeftY,scene.width,scene.height, main="Simulation of Bouncing Ball - www.gekkoquant.com",xlab="",ylab="Ball Height",xaxt="n")   #Draw the platform the ball lands on createBoxFunc(platform.x,platform.y,platform.width,platform.height,platform.colour)   #Draw a box on the left off the platform createBoxFunc(leftbluebox.x,leftbluebox.y,leftbluebox.width,leftbluebox.height,leftbluebox.colour)   #Draw a box on the right of the platform createBoxFunc(rightbluebox.x,rightbluebox.y,rightbluebox.width,rightbluebox.height,rightbluebox.colour)   #Draw the ball createCircleFunc(ball.x,ball.y,ball.radius,ball.colour,borderColour=NA)   #Plot the logged variables plot(logger.yposition, type="l", ylim=plotcontrol.yposition.ylim, ylab="Y POSITION") plot(logger.yvelocity, type="l", ylim=plotcontrol.yvelocity.ylim, ylab="Y VELOCITY") plot(logger.yacceleration, type="l",ylim=plotcontrol.yacceleration.ylim, ylab="Y ACCELERATION")   #Plot a progress bar par(mar=c(2,1,1,1)) plot(-5, xlim = c(1,simulation.numoftimesteps), ylim = c(0, .3), yaxt = "n", xlab = "", ylab = "", main = "Iteration") abline(v=i, lwd=5, col = rgb(0, 0, 255, 255, maxColorValue=255))   } }   oopt = ani.options(ani.width = 1200, ani.height = 800, other.opts = "-pix_fmt yuv420p -b 600k") saveVideo(runSimulationFunc(),interval = simulation.timestep,ani.options=oopt,video.name="bounce.mp4") ani.options(oopt)
